B94H Classic
CAD 150.00 CAD 300.00Price range: CAD 150.00 through CAD 300.00
The B94H Classic offers smooth, open neck tones and a focused, articulate bridge with tight lows and expressive mids. A balanced humbucker set that defines the BTone Classic sound.
- Description
- Demo Videos
- Live Videos
- Tech Specs
- Reviews
- Dimensions
- Wiring Diagrams
- 4-Conductor Wiring
- The Story
- Additional information
B94H Classic (P.A.F) — Balanced, Clear, and Focused
The B94H Classic is a calibrated humbucker set designed for balance, clarity, and controlled punch. Wound for versatility in both neck and bridge positions, it delivers a familiar humbucker response with enhanced articulation — blending classic feel with modern consistency.
From warm cleans to confident drive tones, the response stays smooth, expressive, and naturally controlled.
Neck
≈ 7.4 kΩ
Warm, clear, and highly usable.
- Rounded, smooth highs
- Open, balanced mids
- Full lows with clear definition
Perfect for clean passages, expressive lead phrasing, and edge-of-breakup tones without muddiness.
Bridge
≈ 8.1 kΩ
The most assertive of the set.
- Tight, controlled low end
- Focused midrange presence
- Smooth highs that cut without harshness
Great for classic rock punch, articulate leads, and mix-cutting clarity without excessive output.
Who It’s For
Key Benefits
- Balanced, classic humbucker sound
- Smooth highs and defined lows
- Excellent note separation and articulation
- Lightly offset coils (~200-wind difference) for added harmonic complexity
- Versatile from clean to edge-of-breakup
Construction
Hand-wound in Canada with Alnico V bar magnets, 42 AWG plain-enamel wire, vintage-style fiber flatwork, and lightly offset coils. Wax-potted for stability and consistency.
Nitro dipped and wax-potted for stability.
Configuration
Neck Pickup
Slug Coil: North Up • CCW
Screw Coil: South Up • CW
Bridge Pickup
Slug Coil: North Up • CCW
Screw Coil: South Up • CW
Recommended Pots: 500 kΩ
Tone Cap: 0.022 µF
Includes: Neck and Bridge humbuckers (sold individually or as a calibrated set)
Demo Videos
Subscribe to the BTone channel
Live Videos
Tech Specs
| SPEC (B94H Classic) | VALUE |
|---|---|
| Neck Ohm Reading: | ≈ 7.4 kΩ |
| Bridge Ohm Reading: | ≈ 8.1 kΩ |
| Polarity / Wind (Neck): | Slug Coil – North Up / Counter-Clockwise Screw Coil – South Up / Clockwise |
| Polarity / Wind (Bridge): | Slug Coil – North Up / Counter-Clockwise Screw Coil – South Up / Clockwise |
| Magnet Type: | Alnico V Bar |
| Wire Type: | 42 AWG Plain-Enamel |
| Pot Value (Recommended): | 500 kΩ Volume / Tone |
| Tone Cap Value: | 0.022 µF (Standard Humbucker Roll-Off) |
1. Ohm readings may vary slightly due to temperature, multimeter calibration, and material variances.
2. Tone caps for humbuckers typically range from 0.022 µF to 0.015 µF. Larger values roll off more highs; smaller values retain more top-end clarity.
3. Recommendation: 0.022 µF for a balanced, classic humbucker response.
4. Wax potted for stability and feedback resistance.
Reviews
Dimensions
Wiring Diagrams
4-Conductor Wiring
The Story
It All Started Here
The B94 Classic is the foundation — the first voicing James Buddy Rogers built for his own Strat back in 1994.
That tone became the blueprint for everything that followed, shaping the sound, feel, and identity of BTone from day one.
James has always been a single-coil player at heart. That’s where the BTone voice was defined — clarity, balance, response, and touch. But the world of guitars is bigger than any one format. Different instruments demand different geometries, and great tone shouldn’t stop at single coils.
So the original B94 philosophy was carried forward into humbuckers and other pickup designs — not by abandoning its roots, but by translating the same intent into new forms. Same balance. Same feel. Same standard.
Different shape. Same voice.
Built by hand. Played with purpose.
The B94 Classic is pure, honest tone — defined by intention, not format. Just like the year it was born.
| Weight | .35 kg |
|---|---|
| Dimensions | 13 × 13 × 8 cm |
| Pickups | Set of 2 (Neck & Bridge), Neck Pickup Only, Bridge Pickup Only |
| Spacing | 50mm, 52mm, (50mm Neck, 52mm Bridge), (50mm Neck, 50mm Bridge) |
| Lead Type | Braided Shield, 4-Conductor Shielded |
| Cover | Double Black, Zebra, Gold Cover, Chrome Cover, Open Black, Open Gold, Open Chrome, Closed Black, Closed Gold, Closed Chrome |
